DJI RS 2 Gimbal & Nanuk 930 Case Kit Gimbal Stabilizer / RS 2

The DJI RS 2 is a redesigned follow-up to the Ronin-S gimbal with a payload of up to 10 lb. It's about 25% lighter and more compact thanks to monocoque carbon fiber axis arms and a shorter grip handle with a smaller battery cartridge, although still with 12-hour runtime. The motors are about 20% more powerful and support cameras such as the Blackmagic Pocket 6K, Canon 1D X Mark III, Sony a7S III, and ALEXA Mini LF.

The RS 2 also has a 1.4" full-color LCD touchscreen that allows you to access gimbal settings as well as features such as time-lapse and hyper-lapse, which were previously accessible only via the companion mobile app.

The RS 2 uses the DJI Titan stabilization algorithm to provide improved stabilization with increased smoothness. In applications with up to 100mm zoom lenses, a built-in feature called SuperSmooth complements the algorithm by compensating for micromovements and increasing torque to achieve fluid motion (optional lens support is required).

There are also two RSA ports with electrical contacts for dedicated accessories, and each port has a NATO mount for quick-release attachment of these optional accessories. One RSA port is provided on the left and one on the right side of the gimbal. Supported accessories include a focus wheel, a twist-grip dual handle, and a universal mount for efficiently attaching the gimbal to a car, jib, or slider.

The companion iOS/Android Ronin app offers many creative features in addition to standard time-lapse and panorama functions. Time Tunnel combines roll motion with hyper-lapse to "twist" space and time. The track allows you to create a repeatable camera movement path for a tightly choreographed shot. Force Mobile makes the gimbal follow your smartphone's movements. Force Mobile can also be achieved with enhanced responsiveness when you use the optional DJI RavenEye 1080p transmission system. As mentioned, many of these features can be accessed from the touchscreen LCD of the RS 2. When you use the optional RavenEye system, you can also display a live view of your subjects on the touchscreen when using RavenEye's ActiveTrack feature.

The RS 2 uses a dual-layer Manfrotto plus Arca-Swiss camera mounting system with two removable quick release plates. For social media content, the gimbal can be adjusted at the tab of a button to position your camera into portrait mode. To let you efficiently balance your camera, the RS 2 has an axis lock on each axis, so you can unlock and balance one axis at a time. Additionally, a fine-tune balancing knob allows you to further dial in the optimal balance for your camera.

Features:

• 10 lb payload
• Supports larger cameras such as the Blackmagic Pocket 6K and ALEXA Mini LF
• 1.4" full-color LCD touchscreen (with access to features such as time-lapse and hyper-lapse)
• DJI Titan stabilization algorithm
• SuperSmooth stabilization feature for long zoom lenses
• Two RSA ports with electrical contacts and a NATO mount for quick-release attachment of dedicated accessories such as a focus wheel
• Support for an optional DJI RavenEye 1080p transmission system
• Monocoque carbon fiber axis arms
• Short grip handle with a compact 12-hour battery cartridge
• iOS 11+ / Android 7.0+ companion app
• Creative functions such as Time Tunnel and Force Mobile
• Dual-layer Manfrotto plus Arca-Swiss camera mounting system
• Single-tap switching to portrait mode
• Axis locks and fine-tune knob for efficient and precision camera balancing
• Splash-proof carry case included

Specifications:

• Gimbal:
• Number of Axes: 3-Axis (Pitch, Roll, Yaw)
• Rotation Range: Yaw (Pan): 360°
• Pitch (Tilt): -112 to 214°
• Roll: -95 to 240°
• Follow Speed Pan: 360°/s
• Tilt: 360°/s
• Roll: 360°/s
• Load Capacity: 10 lb / 4.5 kg

• Compatibility:
• Camera Mounting Screw: 1 x 1/4"-20 Male

• Connectivity:
• Ports: 2 x RSA
• 3 x USB: Type-C
• Wireless Frequency: 2.4 GHz (2.4 - 2.483)
• Wireless Protocol: Bluetooth 5.0

• Battery:
• Capacity (mAh): 1950 mAh
• Capacity (Wh): 30.3 Wh
• Battery Runtime: 12 Hours
• Battery Chemistry: Lithium-Ion Polymer (LiPo)
• Voltage: 15.4 VDC

• Environmental:
• Operating Temperature: -4 to 113°F / -20 to 45°C

• General:
• Materials: Aluminum, Carbon Fiber, Plastic
• Mounting: 1 x 1/4"-20 Female
• 1 x Cold: Shoe Mount
• Dimensions: 16.1 x 10.2 x 7.7" / 410 x 260 x 195 mm
• Weight: 2.36 lb / 1.07 kg
• 2.595 lb / 1.177 kg (with Camera Plate)
• 2.948 lb / 1.337 kg (with Handlebar)
• Remote

• Packaging Info:
• Package Weight: 7.28 lb
• Box Dimensions (LxWxH): 13.2 x 10.9 x 6.5"
