MAG 424 W3 HEVC IPTV Set Top Box Latest Model Genuine - Bundle Pack
MAG424/W3 is an improved version of the base model MAG424 with a built-in Wi-Fi module of 802.11a/b/g/n/ac standard. Wi-Fi works feature is dual-band so that supports both 2.4 GHz and 5 GHz channels.
Features:
- Easy to Connect:- A built-in Wi-Fi module (for MAG424w3), USB 3.0 and Bluetooth 4.1 support allow connecting any external drive for extra storage space or a keyboard and mouse for comfortably using the set-top box.
-
High Performance: Modern high-performance processor on the HiSilicon chipset Hi3798MV200 and 1 GB RAM is good enough to playback 4K video.
-
Intuitive Interface: The interface strictly observes Google’s UI design guidelines, so it looks familiar to both the operator and the viewer.
-
Ergonomic design: The set-top box and remote control are presented in the new Micro Fusion design. They will look good in any interior.
-
4K and HEVC Support: With HEVC, 4K video can be efficiently transmitted throw modern fiber-optics networks. MAG424 is a great example of high-quality HEVC support by both the hardware and software of the device.
Specifications:
Hardware
- Chipset: Hi3798MV200
- Processor: ARM Cortex A53 Quad Core CPU 1200 MHz
- Performance: 15 000 DMIPS
- RAM: 1 GB
- Flash Memory: 8Gb eMMC
Software
- Operating system: Linux 4.4.35
- Middleware Supported: Ministra multiscreen TV platform
- Interfaces: RCA 3.5 mm, HDMI 2.0, S/PDIF, Ethernet 100 Mbps, USB 2.0х1, USB 3.0x1, Bluetooth 3.0, 4.1, Wi-Fi 2T2R ac
- Sources of media content: PC and NAS in local network, Stream media protocols (RTSP, RTP, UDP, IGMP, HTTP), USB-devices
Audio & Video
- Audio Codecs: MPEG-1 I/II, MPEG-2 II, III (mp3), Dolby Digital Plus, AAC-LC, HE-AAC v1, HE-AAC v2
- Audio Formats: MP3, MPA, M4A, OGG, WAV, AAC
- Video Modes: PAL, NTSC, 576p, 720p, 1080p, 1080i, 2160p
- Video Codecs: H.265 (HEVC), H.264 (AVC, MVC), MPEG-1/2, MPEG-4
- Video Containers: S, MTS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB, 3GP Image formats JPEG, PNG, BMP, GIF, RAW
- Subtitles: DVB, PGS, Hardsub, Inserted, SRT, SSA/ASS, SUB, Teletextsubs, WebVtt, Closed Caption
- Playlist Formats: M3U, M3U8, PLS, CUE
Standard Set
- MAG424w3 Set-Top Box, User Manual, HDMI cable, Power adapter 12V 1A, Remote control, 2 AAA batteries, Packaging
Select Size
From $108.00
MAG 424 W3 HEVC IPTV Set Top Box Latest Model Genuine - Bundle Pack—
$108.00
Description
MAG424/W3 is an improved version of the base model MAG424 with a built-in Wi-Fi module of 802.11a/b/g/n/ac standard. Wi-Fi works feature is dual-band so that supports both 2.4 GHz and 5 GHz channels.
Features:
- Easy to Connect:- A built-in Wi-Fi module (for MAG424w3), USB 3.0 and Bluetooth 4.1 support allow connecting any external drive for extra storage space or a keyboard and mouse for comfortably using the set-top box.
-
High Performance: Modern high-performance processor on the HiSilicon chipset Hi3798MV200 and 1 GB RAM is good enough to playback 4K video.
-
Intuitive Interface: The interface strictly observes Google’s UI design guidelines, so it looks familiar to both the operator and the viewer.
-
Ergonomic design: The set-top box and remote control are presented in the new Micro Fusion design. They will look good in any interior.
-
4K and HEVC Support: With HEVC, 4K video can be efficiently transmitted throw modern fiber-optics networks. MAG424 is a great example of high-quality HEVC support by both the hardware and software of the device.
Specifications:
Hardware
- Chipset: Hi3798MV200
- Processor: ARM Cortex A53 Quad Core CPU 1200 MHz
- Performance: 15 000 DMIPS
- RAM: 1 GB
- Flash Memory: 8Gb eMMC
Software
- Operating system: Linux 4.4.35
- Middleware Supported: Ministra multiscreen TV platform
- Interfaces: RCA 3.5 mm, HDMI 2.0, S/PDIF, Ethernet 100 Mbps, USB 2.0х1, USB 3.0x1, Bluetooth 3.0, 4.1, Wi-Fi 2T2R ac
- Sources of media content: PC and NAS in local network, Stream media protocols (RTSP, RTP, UDP, IGMP, HTTP), USB-devices
Audio & Video
- Audio Codecs: MPEG-1 I/II, MPEG-2 II, III (mp3), Dolby Digital Plus, AAC-LC, HE-AAC v1, HE-AAC v2
- Audio Formats: MP3, MPA, M4A, OGG, WAV, AAC
- Video Modes: PAL, NTSC, 576p, 720p, 1080p, 1080i, 2160p
- Video Codecs: H.265 (HEVC), H.264 (AVC, MVC), MPEG-1/2, MPEG-4
- Video Containers: S, MTS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB, 3GP Image formats JPEG, PNG, BMP, GIF, RAW
- Subtitles: DVB, PGS, Hardsub, Inserted, SRT, SSA/ASS, SUB, Teletextsubs, WebVtt, Closed Caption
- Playlist Formats: M3U, M3U8, PLS, CUE
Standard Set
- MAG424w3 Set-Top Box, User Manual, HDMI cable, Power adapter 12V 1A, Remote control, 2 AAA batteries, Packaging
